DEMAG LIG TYPE R. SOCKET

Brand: DEMAG
Standard: EN 12385
Designation: Safety latch for lifting hooks. Designed to close the hook opening and prevent accidental disengagement of a shackle, sling, or lifting link from the hook during operation and movement.
A safety component that does not carry load, intended to ensure the load remains secured within the hook.

DEMAG LIG TYPE R. SOCKET

Brand: DEMAG
Standard: EN 12385
Designation: Safety latch for lifting hooks. Designed to close the hook opening and prevent accidental disengagement of a shackle, sling, or lifting link from the hook during operation and movement.
A safety component that does not carry load, intended to ensure the load remains secured within the hook.

Serial Number	Cable Q Range	G (mm)	Nominal Size	Permissible Dim	Casting Weight (Potting) (kg)	A (mm)	E (mm)	F (mm)	G (mm)	R (mm)	Unit Weight (kg)
ED-LIG-DEM-05T	18	5	1.5	0.723	560	114	84	21	5	245	1.3
ED-LIG-DEM-06T	19-20	6	2	0.78	630	129	84	23	6	310	1.6
ED-LIG-DEM-07T	22-24	7	2	1.36	710	140	100	26	7	310	2.4
ED-LIG-DEM-08T	26	8	2	1.4	800	158	100	28	8	350	2.6
ED-LIG-DEM-09T	28	9	2	2.3	900	171	120	31	9	350	3.6
ED-LIG-DEM-10T	32	10	2	2.65	1000	190	120	32	10	445	4.4
ED-LIG-DEM-11T	35	11	2	4.3	1120	203	142	36	11	445	6
ED-LIG-DEM-12T	36	12	2.5	4.1	1120	225	142	39	12	495	7.5
ED-LIG-DEM-13T	40	13	2.5	6.5	1250	242	166	43	13	555	9
ED-LIG-DEM-15T	48	15	2.5	6.7	1600	286	166	49	15	595	12.5
ED-LIG-DEM-17T	64	17	2.5	10	2100	400	250	75	17	950	30
